Replacing the solid-state drive
WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in Before Working Inside Your Computer. After working inside your computer, follow the
instructions in
After Working Inside Your Computer. For more safety best practices, see the Regulatory Compliance
home page at dell.com/regulatory_compliance.
CAUTION: Solid-state drives are fragile. Exercise care when handling the hard drive.
Procedure
1 Slide the solid-state drive into the slot on the solid-state drive assembly.
2 Replace the screw that secures the solid-state drive to the solid-state drive assembly.
3 Align the screw holes on the solid-state drive assembly with the screw holes on the computer base.
4 Replace the screws that secure the solid-state drive assembly to the computer base.
5 Connect the solid-state drive cable to the system board.
6 Align the screw holes on the solid-state drive bracket with the screw holes on the solid-state drive assembly.
7 Replace the screws that secure the solid-state drive bracket to the solid-state drive assembly.
Post-requisites
Replace the base panel.
