Alienware 13 - Replacing the Display Panel; Procedure; Post-Requisites

Replacing the display panel
WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in Before Working Inside Your Computer. After working inside your computer, follow the
instructions in
After Working Inside Your Computer. For more safety best practices, see the Regulatory Compliance
home page at dell.com/regulatory_compliance.
Procedure
NOTE: This chapter is applicable only if you have purchased a laptop with non-touchscreen display.
1 Connect the display cable to the display panel and press down on the connector latch to secure the cable.
2 Turn the display panel over.
3 Align the screw holes on the display panel with the screw holes on the display back-cover.
4 Replace the screws that secure the display panel to the display back-cover.
Post-requisites
1 Replace the display bezel.
2 Replace the display assembly.
3 Follow the procedure from step 5 to step 9 in “Replacing the palm rest”.
4 Follow the procedure from step 3 to step 7 in “Replacing the solid-state drive” .
5 Replace the base panel.
67
