Removing the palm rest
WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in Before Working Inside Your Computer. After working inside your computer, follow the
instructions in
After Working Inside Your Computer. For more safety best practices, see the Regulatory Compliance
home page at dell.com/regulatory_compliance.
Prerequisites
1 Remove the base panel.
2 Follow the procedure from step 1 to step 5 in “Removing the solid-state drive”.
Procedure
1 Lift the latches and disconnect the keyboard and keyboard-backlight cables from the system board.
1 keyboard-backlight cable 2 keyboard cable
23
