Replacing the power-button board
WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in Before Working Inside Your Computer. After working inside your computer, follow the
instructions in
After Working Inside Your Computer. For more safety best practices, see the Regulatory Compliance
home page at dell.com/regulatory_compliance.
Procedure
1 Slide the power-button board cable into the power-button board connector and press down the latch to secure the cable.
2 Align the screw hole on the power-button board with the screw hole on the palm-rest assembly.
3 Replace the screw that secures the power-button board to the palm-rest assembly.
Post-requisites
1 Follow the procedure from step 3 to step 6 in “Replacing the keyboard”.
2 Follow the procedure from step 5 to step 9 in “Replacing the palm rest”.
3 Follow the procedure from step 3 to step 7 in “Replacing the solid-state drive” .
4 Replace the base panel.
