Replacing the display bezel
WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in Before Working Inside Your Computer. After working inside your computer, follow the
instructions in
After Working Inside Your Computer. For more safety best practices, see the Regulatory Compliance
home page at dell.com/regulatory_compliance.
Procedure
NOTE: This chapter is applicable only if you have purchased a laptop with non-touchscreen display.
1 Connect the logo-board cable to the logo board.
2 Slide the display-board cables to their respective connectors on the logo board and press down the latches to secure the
cables.
3 Turn the display bezel over.
4 Align the display bezel with the display back-cover and gently snap the display bezel into place.
Post-requisites
1 Replace the display assembly.
2 Follow the procedure from step 5 to step 9 in “Replacing the palm rest”.
3 Follow the procedure from step 3 to step 7 in “Replacing the solid-state drive” .
4 Replace the base panel.
