Removing the speakers
WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in Before Working Inside Your Computer. After working inside your computer, follow the
instructions in
After Working Inside Your Computer. For more safety best practices, see the Regulatory Compliance
home page at dell.com/regulatory_compliance.
Prerequisites
1 Remove the base panel.
2 Follow the procedure from step 1 to step 5 in “Removing the solid-state drive”.
3 Follow the procedure from step 1 to step 8 in “Removing the palm rest”.
4 Remove the display assembly.
5 Follow the procedure from step 1 to step 5 in “Removing the power-adapter port”.
6 Remove the battery.
Procedure
1 Remove the speaker cable from the routing guides on the computer base.
2 Lift the speakers, along with its cable, o the computer base.
1 tabs 2 speaker cable
3 speakers (2) 4 alignment posts (4)
5 computer base
58
