Replacing the camera
WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in Before Working Inside Your Computer. After working inside your computer, follow the
instructions in
After Working Inside Your Computer. For more safety best practices, see the Regulatory Compliance
home page at dell.com/regulatory_compliance.
Procedure
NOTE: This chapter is applicable only if you have purchased a laptop with non-touchscreen display.
1 Using the alignment posts place the camera module on the display back-cover and snap it into place.
2 Connect the camera cable to the camera module.
Post-requisites
1 Replace the display panel.
2 Replace the display bezel.
3 Replace the display assembly.
4 Follow the procedure from step 5 to step 9 in “Replacing the palm rest”.
5 Follow the procedure from step 3 to step 7 in “Replacing the solid-state drive” .
6 Replace the base panel.
