Main
Second HDD Displays the type of secondary hard-drive installed.
AC Adapter Type Displays the type of AC adapter connected to your
computer.
System Memory Displays the system memory.
Extended Memory Displays the extended memory.
Memory Speed Displays the memory speed.
Advanced
Intel(R) SpeedStep Technology Allows you to enable or disable Intel (R) Speedstep
Technology.
NOTE: If enabled, the processor clock speed and core
voltage are adjusted dynamically based on the
processor load.
Default: Enabled
Virtualization Allows you to enable or disable the Intel Virtualization
technology. Default: Enabled
Integrated NIC Allows you to enable or disable the on-board LAN
controller. Default: Enabled
USB Emulation Allows you to enable or disable the USB emulation feature.
This feature denes how the BIOS, in the absence of a USB-
aware operating system, handles USB devices. USB
emulation is always enabled during POST.
NOTE: You cannot boot any type of USB device
(oppy, hard drive, or memory key) when this option
is o.
Default: Enabled
USB PowerShare Allows you to charge USB devices when the computer is
turned o or in standby mode. Default: Enabled
USB Wake Support Allows you to enable USB devices to wake the computer
from standby or to disable the USB wake support feature.
NOTE: If USB PowerShare is enabled, a device
connected to the USB PowerShare connector may not
wake the computer.
Default: Disabled
SATA Operation Allows you to congure the operating mode of the
integrated SATA hard drive controller. Default: AHCI
Adapter Warnings Allows you to choose if the computer should display warning
messages when you use AC adapters that are not supported
by your computer. Default: Enabled
Function Key Behavior Allows you to set function key or multimedia key as the
default function key behavior. Default: Function key
Express Charge Allows you to charge your computer battery using Standard
Charge or Express Charge mode. Default: Express Charge
Battery Health Displays the battery health.
External USB Ports Allows you to disable or enable the external USB ports.
Default: Enabled
77

Alienware 13 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Grey
Market positioning	Gaming
Bus type	DMI2
Stepping	D0
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-4210U
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4200 Mobile series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Haswell
Processor frequency	1.7 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.7 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	4x1, 2x4
Thermal Design Power (TDP)	15 W
Maximum number of PCI Express lanes	12
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	16 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3L-SDRAM
Memory layout (slots x size)	2 x 8 GB
AC adapter included	Yes
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
HDD size	2.5 \
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Total storage capacity	256 GB
Number of SSDs installed	1
Pixel pitch	0.153 x 0.153 mm
Display diagonal	13.3 \
Native aspect ratio	16:9
On-board graphics card ID	0xA16
On-board graphics card model	Intel® HD Graphics 4400
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	200 MHz
On-board graphics card dynamic frequency (max)	1000 MHz
Audio system	Creative Sound Blaster X-Fi MB3
Speaker power	2 W
Video capturing speed	30 fps
Front camera resolution (numeric)	2.1 MP
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI version	1.4
Charging port type	DC-in jack
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Pointing device	Touchpad
Trial software	Microsoft Office
Operating system language	Multilingual
Operating system installed	Windows 8.1 Pro
Processor code	SR1EF
Processor ARK ID	81016
Intel TSX-NI version	0.00
Processor package size	40 x 24 x 1.5 mm
Intel ME Firmware Version	9.5
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Smart Connect Technology version	1.00
Battery voltage	14.8 V
Battery capacity	51 Wh
Battery life (max)	- h
Battery recharge time	4 h
AC adapter power	130 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	6.7 A
AC adapter output voltage	19.5 V
Cable lock slot type	Noble
Operating shock	110 G
Operating altitude	-15.2 - 3048 m
Non-operating shock	160 G
Operating vibration	0.66 G
Non-operating altitude	-15.2 - 10668 m
Non-operating vibration	1.30 G
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	235 mm
Width	328 mm
Weight	2000 g
Height (rear)	27.9 mm
Height (front)	25.34 mm
