Alienware Area-51 m7700 - Page 109

Upgrading The Computer
Upgrading the Hard Disk Drive(s) 6 - 5
6
1. Turn off the computer, and turn it over and remove the battery.
2. Locate the hard disk bay cover and remove screws
- .
3. Remove the bay cover .
1 4
5
Figure 6 - 2
HDD Bay Cover
Removal
1
3 4
2
5
