Drivers & Utilities
RAID Mode Configuration 4 - 11
4
13. Press <4> to enter the Delete Array Menu in order to delete existing arrays (press <Esc> to return to the
Main Menu).
14. Press <1> to enter the Auto Setup Menu (recommended) as this is the easiest and fastest way to setup
your first array. Use <Spacebar> to cycle through the “Optimize Array for” section for Performance
(RAID 0, Stripe) or Security (RAID 1, Mirror) RAID mode, and then press <Ctrl> + <Y> to save your
selection.
15. If you wish to define an array manually then press <3> from the Main Menu (this will bring up the Define
Array Menu - See Figure 4 - 11).
16. To create an array manually from the Define Array Menu (Figure 4 - 11) use the arrow keys to highlight
any array you wish to define, then press <Enter> to select it.
Mode......................................Stripe
Spare Drive...............................0
Drive(s) used in Array....................2
Array Disk Capacity (size in MB)..........200060
FastBuild (tm) Utility 2.01 (c) 2002-2005 Promise Technology, Inc.
[ Auto Setup Options Menu ]
Optimize Array for: Performance
[ Array Setup Configuration ]
[ Keys Available ]
[← , , Space] Change Option [Esc] Exit [Ctrl-Y] Save
Figure 4 - 10
FastBuild Utility
(Auto Setup Menu)
