Removing the Center Control Cover | 27
CAUTION: Be extremely careful when removing the center control
cover. The cover along with the cable that attaches to it are fragile.
2 Turn the computer over and open the display as far as possible.
3 Gently pry up the center control cover and then ease the tabs on the center control
cover out of the slots on the palm-rest assembly.
1 center control cover 2 palm-rest assembly
1
2
Book.book Page 27 Thursday, April 19, 2012 2:38 PM
