Pin Assignment of Board to Board Connectors CON3
CON1
Pin
Signal Name
FPGA
Pin
Voltage
Level
CON1
Pin
Signal Name
FPGA Pin
Voltage
Level
PIN1
B15_IO0
J16
3.3V
PIN2
B15_IO25
M17
3.3V
PIN3
B16_IO0
F15
3.3V
PIN4
B16_IO25
F21
3.3V
PIN5
B15_L4_P
G17
3.3V
PIN6
B16_L21_N
A21
3.3V
PIN7
B15_L4_N
G18
3.3V
PIN8
B16_L21_P
B21
3.3V
PIN9
GND
-
Ground
PIN10
GND
-
Ground
PIN11
B15_L2_P
G15
3.3V
PIN12
B16_L23_P
E21
3.3V
PIN13
B15_L2_N
G16
3.3V
PIN14
B16_L23_N
D21
3.3V
PIN15
B15_L12_P
J19
3.3V
PIN16
B16_L22_P
E22
3.3V
PIN17
B15_L12_N
H19
3.3V
PIN18
B16_L22_N
D22
3.3V
PIN19
GND
-
Ground
PIN20
GND
-
Ground
PIN21
B15_L11_P
J20
3.3V
PIN22
B16_L24_P
G21
3.3V
PIN23
B15_L11_N
J21
3.3V
PIN24
B16_L24_N
G22
3.3V
PIN25
B15_L1_N
G13
3.3V
PIN26
B15_L8_N
G20
3.3V
PIN27
B15_L1_P
H13
3.3V
PIN28
B15_L8_P
H20
3.3V
PIN29
GND
-
Ground
PIN30
GND
-
Ground
PIN31
B15_L5_P
J15
3.3V
PIN32
B15_L7_N
H22
3.3V
PIN33
B15_L5_N
H15
3.3V
PIN34
B15_L7_P
J22
3.3V
PIN35
B15_L3_N
H14
3.3V
PIN36
B15_L9_P
K21
3.3V
PIN37
B15_L3_P
J14
3.3V
PIN38
B15_L9_N
K22
3.3V
PIN39
GND
-
Ground
PIN40
GND
-
Ground
PIN41
B15_L19_P
K13
3.3V
PIN42
B15_L15_N
M22
3.3V
PIN43
B15_L19_N
K14
3.3V
PIN44
B15_L15_P
N22
3.3V
PIN45
B15_L20_P
M13
3.3V
PIN46
B15_L6_N
H18
3.3V
PIN47
B15_L20_N
L13
3.3V
PIN48
B15_L6_P
H17
3.3V
PIN49
GND
-
Ground
PIN50
GND
-
Ground
PIN51
B15_L14_P
L19
3.3V
PIN52
B15_L13_N
K19
3.3V
PIN53
B15_L14_N
L20
3.3V
PIN54
B15_L13_P
K18
3.3V
PIN55
B15_L21_P
K17
3.3V
PIN56
B15_L10_P
M21
3.3V
