ARTIX-7 FPGA Development Board AX7101 User Manual
28 / 51
www.alinx.com
PIN15
GND
-
Ground
PIN16
GND
-
Ground
PIN17
MGT_TX3_P
D7
Differential
PIN18
MGT_RX2_P
B10
Differential
PIN19
MGT_TX3_N
C7
Differential
PIN20
MGT_RX2_N
A10
Differential
PIN21
GND
-
Ground
PIN22
GND
-
Ground
PIN23
MGT_RX3_P
D9
Differential
PIN24
MGT_TX0_P
B4
Differential
PIN25
MGT_RX3_N
C9
Differential
PIN26
MGT_TX0_N
A4
Differential
PIN27
GND
-
Ground
PIN28
GND
-
Ground
PIN29
MGT_TX1_P
D5
Differential
PIN30
MGT_RX0_P
B8
Differential
PIN31
MGT_TX1_N
C5
Differential
PIN32
MGT_RX0_N
A8
Differential
PIN33
GND
-
Ground
PIN34
GND
-
Ground
PIN35
MGT_RX1_P
D11
Differential
PIN36
MGT_CLK1_P
F10
Differential
PIN37
MGT_RX1_N
C11
Differential
PIN38
MGT_CLK1_N
E10
Differential
PIN39
GND
-
Ground
PIN40
GND
-
Ground
PIN41
B16_L5_P
E16
3.3V
PIN42
B16_L2_P
F16
3.3V
PIN43
B16_L5_N
D16
3.3V
PIN44
B16_L2_N
E17
3.3V
PIN45
B16_L7_P
B15
3.3V
PIN46
B16_L3_P
C14
3.3V
PIN47
B16_L7_N
B16
3.3V
PIN48
B16_L3_N
C15
3.3V
PIN49
GND
-
Ground
PIN50
GND
-
Ground
PIN51
B16_L9_P
A15
3.3V
PIN52
B16_L10_P
A13
3.3V
PIN53
B16_L9_N
A16
3.3V
PIN54
B16_L10_N
A14
3.3V
PIN55
B16_L11_P
B17
3.3V
PIN56
B16_L12_P
D17
3.3V
PIN57
B16_L11_N
B18
3.3V
PIN58
B16_L12_N
C17
3.3V
PIN59
GND
-
Ground
PIN60
GND
-
Ground
PIN61
B16_L13_P
C18
3.3V
PIN62
B16_L14_P
E19
3.3V
PIN63
B16_L13_N
C19
3.3V
PIN64
B16_L14_N
D19
3.3V
PIN65
B16_L15_P
F18
3.3V
PIN66
B16_L16_P
B20
3.3V
PIN67
B16_L15_N
E18
3.3V
PIN68
B16_L16_N
A20
3.3V
PIN69
GND
-
Ground
PIN70
GND
-
Ground
PIN71
B16_L17_P
A18
3.3V
PIN72
B16_L18_P
F19
3.3V
PIN73
B16_L17_N
A19
3.3V
PIN74
B16_L18_N
F20
3.3V
PIN75
B16_L19_P
D20
3.3V
PIN76
B16_L20_P
C22
3.3V
PIN77
B16_L19_N
C20
3.3V
PIN78
B16_L20_N
B22
3.3V
