ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
8 / 29
Amazon Store: https://www.amazon.com/alinx
PS_DDR4_DQS2_P
PS_DDR_DQS_P2_504
AF25
PS_DDR4_DQS2_N
PS_DDR_DQS_N2_504
AF26
PS_DDR4_DQS3_P
PS_DDR_DQS_P3_504
AE27
PS_DDR4_DQS3_N
PS_DDR_DQS_N3_504
AF27
PS_DDR4_DQ0
PS_DDR_DQ0_504
AD21
PS_DDR4_DQ1
PS_DDR_DQ1_504
AE20
PS_DDR4_DQ2
PS_DDR_DQ2_504
AD20
PS_DDR4_DQ3
PS_DDR_DQ3_504
AF20
PS_DDR4_DQ4
PS_DDR_DQ4_504
AH21
PS_DDR4_DQ5
PS_DDR_DQ5_504
AH20
PS_DDR4_DQ6
PS_DDR_DQ6_504
AH19
PS_DDR4_DQ7
PS_DDR_DQ7_504
AG19
PS_DDR4_DQ8
PS_DDR_DQ8_504
AF22
PS_DDR4_DQ9
PS_DDR_DQ9_504
AH22
PS_DDR4_DQ10
PS_DDR_DQ10_504
AE22
PS_DDR4_DQ11
PS_DDR_DQ11_504
AD22
PS_DDR4_DQ12
PS_DDR_DQ12_504
AH23
PS_DDR4_DQ13
PS_DDR_DQ13_504
AH24
PS_DDR4_DQ14
PS_DDR_DQ14_504
AE24
PS_DDR4_DQ15
PS_DDR_DQ15_504
AG24
PS_DDR4_DQ16
PS_DDR_DQ16_504
AC26
PS_DDR4_DQ17
PS_DDR_DQ17_504
AD26
PS_DDR4_DQ18
PS_DDR_DQ18_504
AD25
PS_DDR4_DQ19
PS_DDR_DQ19_504
AD24
PS_DDR4_DQ20
PS_DDR_DQ20_504
AG26
PS_DDR4_DQ21
PS_DDR_DQ21_504
AH25
PS_DDR4_DQ22
PS_DDR_DQ22_504
AH26
PS_DDR4_DQ23
PS_DDR_DQ23_504
AG25
PS_DDR4_DQ24
PS_DDR_DQ24_504
AH27
PS_DDR4_DQ25
PS_DDR_DQ25_504
AH28
PS_DDR4_DQ26
PS_DDR_DQ26_504
AF28
PS_DDR4_DQ27
PS_DDR_DQ27_504
AG28
PS_DDR4_DQ28
PS_DDR_DQ28_504
AC27
PS_DDR4_DQ29
PS_DDR_DQ29_504
AD27
PS_DDR4_DQ30
PS_DDR_DQ30_504
AD28
PS_DDR4_DQ31
PS_DDR_DQ31_504
AC28
