PS_DDR4_DM0
PS_DDR_DM0_504
AG20
PS_DDR4_DM1
PS_DDR_DM1_504
AE23
PS_DDR4_DM2
PS_DDR_DM2_504
AE25
PS_DDR4_DM3
PS_DDR_DM3_504
AE28
PS_DDR4_A0
PS_DDR_A0_504
W28
PS_DDR4_A1
PS_DDR_A1_504
Y28
PS_DDR4_A2
PS_DDR_A2_504
AB28
PS_DDR4_A3
PS_DDR_A3_504
AA28
PS_DDR4_A4
PS_DDR_A4_504
Y27
PS_DDR4_A5
PS_DDR_A5_504
AA27
PS_DDR4_A6
PS_DDR_A6_504
Y22
PS_DDR4_A7
PS_DDR_A7_504
AA23
PS_DDR4_A8
PS_DDR_A8_504
AA22
PS_DDR4_A9
PS_DDR_A9_504
AB23
PS_DDR4_A10
PS_DDR_A10_504
AA25
PS_DDR4_A11
PS_DDR_A11_504
AA26
PS_DDR4_A12
PS_DDR_A12_504
AB25
PS_DDR4_A13
PS_DDR_A13_504
AB26
PS_DDR4_WE_B
PS_DDR_A14_504
AB24
PS_DDR4_CAS_B
PS_DDR_A15_504
AC24
PS_DDR4_RAS_B
PS_DDR_A16_504
AC23
PS_DDR4_ACT_B
PS_DDR_ACT_N_504
Y23
PS_DDR4_ALERT_B
PS_DDR_ALERT_N_504
U25
PS_DDR4_BA0
PS_DDR_BA0_504
V23
PS_DDR4_BA1
PS_DDR_BA1_504
W22
PS_DDR4_BG0
PS_DDR_BG0_504
W24
PS_DDR4_CS0_B
PS_DDR_CS_N0_504
W27
PS_DDR4_ODT0
PS_DDR_ODT0_504
U28
PS_DDR4_PARITY
PS_DDR_PARITY_504
V24
PS_DDR4_RESET_B
PS_DDR_RST_N_504
U23
PS_DDR4_CLK0_P
PS_DDR_CK0_P_504
W25
PS_DDR4_CLK0_N
PS_DDR_CK0_N_504
W26
PS_DDR4_CKE0
PS_DDR_CKE0_504
V28
