Input Send Levels (Out 1-6 only) – Select whether send levels from the inputs are
Pre Fader (independent of send levels to the Main LR output) or Post Fader (they
‘follow’ and are relative to the send levels of inputs to the Main LR output).
Follow Main LR Pan (Out 1-6 only) – Available on Outputs which are linked/stereo.
Select whether panning of the inputs to the output are independent to the panning
of inputs to the Main LR output (Off), or whether they follow them in the same
direction (On) or the opposite direction (On – Inv)
The On -Inv setting is useful for stereo on-stage monitoring, being that the left/right
from the stage is the inverse of the left/right from the audience.
Output Delay – Delay each output by up to 682ms. Often used to time align fill
speakers or for synchronising audio to video.
Headphone Output
Source – Select Listen to have the headphone output work with the Listen buttons
(with headphone symbol) on each channel. Set to a mono or stereo mix to use as a
monitor output with independent send levels to the Main LR.
If Listen is set, when no Listen button is pressed, the headphone output will be
sourced from Main LR.
Volume – Set the headphone output level.
Headphone level can also be controlled from the home screen. To access quickly on
the CQ-12T or CQ-18T, press the HOME screen key once or twice to display and adjust.
The CQ-18T has two headphone outputs which can be set up individually. For
example, it is possible to have one headphone output set to Listen and the other to
be fed with one of the monitor mixes.
