82 Rockwell Automation Publication 1734-UM013C-EN-P - August 2010
Chapter 6 Configure the Module in a GuardLogix Controller
Combined Status -
Muting
• A single BOOL tag represents an AND of the status bits for all
the output points. For example, if any output channel has a
fault, this bit goes LO.
(1)
• A single BOOL tag represents the Input Power Status (error
bit) from the input assembly.
• A muting status tag for test output T1 and T3.
Choose Description
