Tag Definitions Appendix B
Pt[x].PWMMinimumOnTime REAL PWM Minimum On Time—Defines the minimum length of time required for the output
to turn On. Requires PWM to be enabled via the Pt[x].PWMEnable tag.
Valid values:
0.0002…3600.0 seconds
or
0…100 percent
Connection = Data
Output Data = Data or Scheduled
per Module
or
Connection = Peer Ownership
Output Data = Data with Peer
OutputMap[x].AndToControllerData INT Controller Data with AND Logic—Determines the output state by applying AND logic
to these sources:
• Corresponding bits from the controller’s output data (O:Data)
• Other mapped bits specified in the output configuration
Connection = Peer Ownership
Output Data = Data with Peer
OutputMap[x].OrToControllerData INT Controller Data with OR Logic—Determines the output state by applying OR logic to
these sources:
• Corresponding bits from the controller’s output data (O:Data)
• Other mapped bits specified in the output configuration
Connection = Peer Ownership
Output Data = Data with Peer
OutputMap[x].AndToPeerInput INT Peer Data with AND Logic—Determines the output state by applying AND logic to
these sources:
• Corresponding bits from peer input data (I:Data)
• Other mapped bits specified in the output configuration
Connection = Peer Ownership
Output Data = Data with Peer
OutputMap[x].OrToPeerInput INT Peer Data with OR Logic—Determines the output state by applying OR logic to these
sources:
• Corresponding bits from peer input data (I:Data)
• Other mapped bits specified in the output configuration
Connection = Peer Ownership
Output Data = Data with Peer
OutputMap[x].AndToPeerWindow0 SINT Peer Data with AND Logic—Determines the output state by applying AND logic to
these sources:
• Corresponding bits from window 0 of the peer counter module
(I:Counter[x].InputWindow0)
• Other mapped bits specified in the output configuration
Connection = Peer Ownership
Output Data = Data with Peer
OutputMap[x].OrToPeerWindow0 SINT
Peer Data with OR Logic—
Determines the output state by applying OR logic to these
sources:
• Corresponding bits from window 0 of the peer counter module
(I:Counter[x].InputWindow0)
• Other mapped bits specified in the output configuration
Connection = Peer Ownership
Output Data = Data with Peer
OutputMap[x].AndToPeerWindow1 SINT Peer Data with AND Logic—Determines the output state by applying AND logic to
these sources:
• Corresponding bits from window 1 of the peer counter module
(I:Counter[x].InputWindow1)
• Other mapped bits specified in the output configuration
Connection = Peer Ownership
Output Data = Data with Peer
OutputMap[x].OrToPeerWindow1 SINT Peer Data with OR Logic—Determines the output state by applying OR logic to these
sources:
• Corresponding bits from window 1 of the peer counter module
(I:Counter[x].InputWindow1)
• Other mapped bits specified in the output configuration
Connection = Peer Ownership
Output Data = Data with Peer
Table 47 - 1756-OB16IEF Module Configuration Tags (continued)
Name Data Type Tag Definition Module Definition
