Rockwell Automation Publication 1756-UM058G-EN-P - November 2012 241
1492 IFMs for Digital I/O Modules Appendix G
Table 65 - IFMs and Prewired Cables
I/O Cat. No. IFM Cat. No. IFM Type IFM Description Prewired Cable
1756-IA8D 1492-IFM20F Feed-through Standard 1492-CABLExU
(x=cable length)
1492-IFM20FN Narrow standard
1492-IFM20F-2 Extra terminals
1492-IFM20D120 Status-indicating Standard with 120V AC/DC status indicators
(1)
1492-IFM20D120N Narrow standard with 120V AC status indicators
1492-IFM20D120A-2 120V AC with extra terminals for inputs
1492-IFM20F-FS120A-4 Fusible Two 4-point isolated groups with four terminals per input and 120V AC/DC blown
fuse indicators
1756-IA16 1492-IFM20F Feed-through Standard 1492-CABLExX
(x=cable length)
1492-IFM20FN Narrow standard
1492-IFM20F-2 Extra terminals
1492-IFM20F-3 3-wire sensor type input devices
1492-IFM20D120 Status-indicating Standard with 120V AC/DC status indicators
(1)
1492-IFM20D120N Narrow standard with 120V AC status indicators
1492-IFM20D120A-2 120V AC with extra terminals for inputs
1492-IFM20F-F120A-2 Fusible Extra terminals with 120V AC/DC blown fuse status indicators.
1756-IA16I 1492-IFM40F Feed-through Standard 1492-CABLExY
(x=cable length)
1492-IFM40DS120A-4 Fusible Isolated with 120 V AC status indicators and four terminals per input
1492-IFM40F-FSA-4 Isolated 120V AC/DC with four terminals per input
1492-IFM40F-FS120A-4 Isolated with 120V AC/DC blown fuse indicators and four terminals per input.
1756-IA32 1492-IFM40F Feed-through Standard 1492-CABLExZ
(x=cable length)
1492-IFM40F-2 Extra terminals
1492-IFM40D120A-2 Status-indicating 120V AC status indicators and extra terminals for inputs
1756-IB16 1492-IFM20F Feed-through Standard 1492-CABLExX
(x=cable length)
1492-IFM20FN Narrow standard
1492-IFM20F-2 Extra terminals
1492-IFM20F-3 3-wire sensor type input devices
1492-IFM20D24 Status-indicating Standard with 24V AC/DC status indicators
1492-IFM20D24N Narrow standard with 24V AC/DC status indicators
1492-IFM20D24A-2 24V AC/DC status indicators and extra terminals for inputs
1492-IFM20D24-3 3-wire sensor with 24V AC/DC status indicators
1492-IFM20F-F24A-2 Fusible Extra terminals with 24V AC/DC blown fuse indicators for inputs
1756-IB16D 1492-IFM40F Feed-through Standard 1492-CABLExY
(x=cable length)
1492-IFM40F-2 Extra terminals
1492-IFM40DS24A-4 Status-indicating Isolated with 24V AC/DC status indicators and four terminals per input
1492-IFM40F-F24AD-4 Fusible Fused with 24V DC blown fuse low leakage indicators, four isolated groups and four
terminals per input
1492-IFM40F-FS24A-4 Isolated with 24V AC/DC blown fuse indicators and four terminals per input
(2)
1492-IFM40F-FSA-4 Isolated with 120V AC/DC with four terminals per input
