Publication 1756-UM001G-EN-P - January 2007
64 Place, Configure, and Monitor I/O Modules
Reconfigure an I/O Module
If an I/O module supports reconfiguration, you can reconfigure the
module via:
• RSLogix 5000 programming software.
• a MSG instruction in program logic.
Reconfigure a Module via RSLogix 5000 Programming Software
To reconfigure a module, perform this procedure.
1. In RSLogix 5000 programming software, right-click a module in
the I/O Configuration tree and select Properties.
The Module Properties dialog appears.
2. Reconfigure the I/O module.
3. Click OK.
WARNING
Use care when changing the configuration of an I/O module.
You could inadvertently cause the I/O module to operate
incorrectly.
