15 Publication 1756-UM001G-EN-P - January 2007
Chapter
2
Directly Connect to the Controller via the
Serial Port
Introduction
This chapter explains how to connect the controller to the serial port
and how to upload and download a project to the controller.
Connect the Controller to
via the Serial Port
To connect a serial cable, perform this procedure.
1. Obtain a 1756-CP3 serial cable.
You can also use a 1747-CP3 cable from the SLC product family,
but once the cable is connected you cannot close the controller
door.
Topic Page
Connect the Controller to via the Serial Port 15
Configure the Serial Driver 17
Select the Controller Path 19
