Publication 1747-UM655B-EN-P - June 2007
Preface 11
Common Techniques Used
in This Manual
The following conventions are used throughout this manual:
Bulleted lists provide information, not procedural steps.
Numbered lists provide sequential steps.
Additional Resources
These documents contain additional information concerning related
Rockwell Automation products.
1 24V power supply Any regulated 24V dc, 8 A -
1 Personal computer IBM-compatible Pentium+
Windows 2000 or later
-
Software
RSLogix 500 9324-RL0300xxx Rev 4.00
RSNetWorx for DeviceNet 9357-DNETL3 Rev 2.22
RSLinx 9355-WAB Rev 2.10
Quantity Product Name Catalog Number Series/Revision
TIP
This symbol identifies helpful tips.
Resource Description
1747-SDN DeviceNet Scanner Module
Installation Instructions, publication 1747-IN058
Provides information on installing
and connecting the module.
ControlFlash Firmware Upgrade Kit Quick Start,
publication 1756-QS105
Provides instructions on using the
ControlFlash utility to upgrade the
firmware.
Getting Results with RSLogix 500, publication
LG500-GR002
Provides information on RSLogix
500 software.
Getting Results with RSLinx Classic, publication
LINX-GR001
Provides information on RSLinx
software.
DeviceNet Media Design and Installation Guide,
publication DNET-UM072
Provides information on using
DeviceNet communication network.
Getting Results with RSNetWorx for DeviceNet,
publication DNET-GR001
Provides information on using
RSNetWorx for DeviceNet
software.
DeviceNet RS-232 Interface Module, publication
1770-5.6
Provides information on connecting
and installing the DeviceNet
RS-232 Interface module.
SLC 500 ControlNet RS-232 Interface User
Manual, publication 1747-5.34
Provides information about the
1747-KFC15 module.
