Publication 1747-UM655B-EN-P - June 2007
Before You Begin 15
Processor to I/O
The 1747-SDN interface module can also be used to bridge a
DeviceNet network with another network.
Configuring Devices and Data Collection on Higher-level Networks via
SLC 500/SDN Module
Configure SDN Module (Chapter 4)
Mapping Table (Chapters 2 and 4)
Input
Device
Output
Device
Input Data from
Device to SDN
(Chapter 2)
Output Write by
Processor (Chapter 2)
DeviceNet Network
Output Data to Devices
from SDN (Chapter 2)
Input Read by Processor (Chapter 2)
Configure SDN Module (Chapter 4)
Computer
Running
RSNetWorx for
DeviceNet
Software
Target device to
be configured.
Source device
to collect data.
Configuration of device
using RSNetWorx
software (Chapter 4).
DeviceNet Network
Industrial
workstation running
RSView software.
Laptop computer
running RSNetWorx
software.
DH+ or Ethernet Network (Chapter 5)
Collection of status
or alarm data
(Chapter 6).
1747-SDN
Module
To Next Page
