4. Select the Allen-Bradley 1770-KFD driver.
The Driver Configuration dialog appears.
5. Configure the driver by using the example above as a guide and
click on OK.
The software takes a few seconds to configure the driver. When
it is done the following prompt appears.
6. Select the default driver name 1770-KFD-1 and click OK.
7. Close RSLinx software.
Use the driver you just configured to browse and configure the
network with RSNetWorx for DeviceNet software.
TIP
Your driver setup depends on your particular system setup
(COM port, communication rate, node address). Choose
the appropriate settings for your system.
