Allen-Bradley powerflex 700 User Manual

3-40 Programming and Parameters
UTILITY
Drive Memory
197 [Reset To Defalts]
Resets parameters to factory defaults
except [Language], [Param Access Lvl],
[Voltage Class] & [TorqProve Cnfg]
(params 196, 201, 202 & 600).
• Option 1 resets parameters to factory
defaults based on [Voltage Class].
• Options 2 & 3 will reset parameters to
factory defaults and set [Voltage
Class] to low or high voltage settings.
Important: Frames 5 & 6 - the internal
fan voltage may have to be changed
when using Option 2 or 3. See “Selecting
/Verifying Fan Voltage” on page 1-8
.
Default:
Options:
0
0
1
2
3
“Ready”
“Ready”
“Factory”
“Low Voltage”
“High Voltage”
041
thru
047
054
055
062
063
069
thru
072
082
148
158
198 [Load Frm Usr Set]
Loads a previously saved set of
parameter values from a selected user
set location in drive nonvolatile memory
to active drive memory.
Default:
Options:
0
0
1
2
3
“Ready”
“Ready”
“User Set 1”
“User Set 2”
“User Set 3”
199
199 [Save To User Set]
Saves the parameter values in active
drive memory to a user set in drive
nonvolatile memory.
Default:
Options:
0
0
1
2
3
“Ready”
“Ready”
“User Set 1”
“User Set 2”
“User Set 3”
198
200 [Reset Meters]
Resets selected meters to zero.
Default:
Options:
0
0
1
2
“Ready”
“Ready”
“MWh”
“Elapsed Time”
201 [Language]
Selects the display language when using
an LCD HIM. This parameter is not
functional with an LED HIM.
Options 6, 8 and 9 are “Reserved.”
Default:
Options:
0
0
1
2
3
4
5
7
10
“Not Selected”
“Not Selected”
“English”
“Francais”
“Español”
“Italiano”
“Deutsch”
“Português”
“Nederlands”
202 [Voltage Class]
Configures the drive current rating and
associates it with the selected voltage
(i.e. 400 or 480V). Normally used when
downloading parameter sets. Options 2 &
3 indicate status only. Selecting Option 4
or 5 will covert/configure the drive. Min/
Max & Default values will be changed for
parameters; 41-47, 54, 55, 62, 63, 69,
70-72, 82, 148, 158.
Important: Frames 5 & 6 - the internal
fan voltage may have to be changed
when using Option 4 or 5. See page 1-8
.
Default:
Options: 2
3
4
5
(1)
Based on Drive Cat.
No.
“Low Voltage”
“High Voltage”
“Reserved”
(1)
“Convert Lo V”
“Reserved”
(1)
“Convert Hi V”
Vector firmware
v3.001 & up.
041
thru
047
054
055
062
063
069
thru
072
082
148
158
File Group No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
Vector
Vector

Allen-Bradley powerflex 700 Specifications

General

Series	PowerFlex 700
Category	AC Drive
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Enclosure	Type 1
Control Method	Sensorless Vector
Communication	EtherNet/IP, ControlNet, DeviceNet, PROFIBUS DP, Modbus
