Access Procedures 3-23
6. Remove the six screws that secure the Power Structure to the enclosure
frame.
7. Follow the instructions in publication PFLEX-IN014, Installation
Instructions - PowerFlex 700S /700H High Power Maintenance Stand,
to install the Maintenance Stand. Remove the power structure by sliding
it onto the rails of the Maintenance Stand.
Note: The Maintenance Stand is designed for removing power
structures from drives supplied in Rittal TS8 enclosures. Alternate
means of removal will be necessary for other types of enclosures.
Remove screws
Remove screws
To Next Page
