Allen-Bradley PowerFlex 750 Series Programming Manual

240 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 5 Embedded Feature and Option Module Parameters
Embedded DeviceLogix
Status & Cntl
51 DLX DigOut Sts2
Provides the individual on/off status of the 16 DLX DOPs.
RO 32-bit
Integer
52 DLX Prog Cond
Defines the action that will be taken when the DLX logic is disabled.
“Fault” (0) – Drive is faulted and stopped.
“Stop” (1) – Drive is stopped, but not faulted.
“Zero Data” (2) – Output data sent to the drive from DLX is zeroed (does not command a
stop).
“Hold Last” (3) – Drive continues in its present state.
Default:
Options:
0 = “Fault”
0 = “Fault”
1 = “Stop”
2 = “Zero Data”
3 = “Hold Last”
RW 32-bit
Integer
53 DLX Operation
Contains both operation commands as well as status information.
Default:
Options:
5 = “Logic Disabled”
0 = “Enable Logic”
1 = “Disable Logic”
2 = “Reset Program”
3 = “Save Program”
4 = “Load Program”
5 = “Logic Disabled”
6 = “Logic Enabled”
RW 32-bit
Integer
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved DLX DOPSts16 DLX DOPSts15 DLX DOPSts14 DLX DOPSts13 DLX DOPSts12 DLX DOPSts11 DLX DOPSts10 DLX DOPSts9 DLX DOPSts8 DLX DOPSts7 DLX DOPSts6 DLX DOPSts5 DLX DOPSts4 DLX DOPSts3 DLX DOPSts2 DLX DOPSts1
Default00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = Condition Off
1 = Condition On
