Allen-Bradley PowerFlex 750 Series Programming Manual

Rockwell Automation Publication 750-PM001N-EN-P - February 2017 241
Embedded Feature and Option Module Parameters Chapter 5
Embedded DeviceLogix
Internal Regs
54
Thru
69
DLX Real SP1
DLX Real SP16
Sixteen 32-bit Real scratchpad registers for DLX program use.
Default:
Min/Max:
0
–/+220000000
RW Real
70
Thru
77
DLX DINT SP1
DLX DINT SP8
Eight 32-bit Integer scratchpad registers for DLX program use.
Default:
Min/Max:
0
–2147483648 / 2147483647
RW 32-bit
Integer
78
Thru
81
DLX Bool SP1
DLX Bool SP4
Four 32-bit Boolean scratchpad registers (128 bits total) for DLX program use.
RW 32-bit
Integer
82
Thru
89
DLX Real In SP1
DLX Real In SP8
Eight 32-bit Real scratchpad registers for DLX program input use.
Default:
Min/Max:
0
–/+220000000
RW Real
90
Thru
97
DLX Real OutSP1
DLX Real OutSP8
Eight 32-bit Real scratchpad registers for DLX program output use.
Default:
Min/Max:
0
–/+220000000
RW Real
98
Thru
101
DLX DINT InSP1
DLX DINT InSP4
Four 32-bit Integer scratchpad registers for DLX program input use.
Default:
Min/Max:
0
–2147483648 / 2147483647
RW 32-bit
Integer
102
Thru
105
DLX DINT OutSP1
DLX DINT OutSP4
Four 32-bit Integer scratchpad registers for DLX program output use.
Default:
Min/Max:
0
–2147483648 / 2147483647
RW 32-bit
Integer
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
Options
Bit 31 Bit 30 Bit 29 Bit 28 Bit 27 Bit 26 Bit 25 Bit 24 Bit 23 Bit 22 Bit 21 Bit 20 Bit 19 Bit 18 Bit 17 Bit 16 Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Default00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = Condition Off
1 = Condition On
