348 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 6 Troubleshooting
xx072 Ch0 ROM Error Configurable P9
[FB0 Loss Cfg]
Error reported by a linear Stahl encoder on Channel 0 - Indicates a ROM
error. Reading head must be repaired
xx074 Ch0 No Position Configurable P9
[FB0 Loss Cfg]
Error reported by a linear Stahl encoder on Channel 0 - Indicates that no
position value was available - only possible following powerup or reset
xx081 Ch0 Msg Cheksum Configurable P9
[FB0 Loss Cfg]
Indicates that the option card has detected a serial communications
checksum error while attempting to communicate with the encoder on
channel 0.
xx082 Ch0 Timeout Configurable P9
[FB0 Loss Cfg]
Indicates that the option card has detected a serial communications
timeout error while attempting to communicate with the encoder on
channel 0.
xx083 Ch0 Comm Configurable P9
[FB0 Loss Cfg]
Indicates that the option card has detected a serial communications
error (other than checksum or timeout) while attempting to
communicate with the encoder on channel 0.
xx084 Ch0 Diagnostic Configurable P9
[FB0 Loss Cfg]
Indicates that the option card has detected a powerup diagnostic test
failure for encoder channel 0.
xx085 Ch0 SpplyVltgRng Configurable P9
[FB0 Loss Cfg]
Indicates that the voltage source to the encoder 0 is out of range.
xx086 Ch0 SC Amplitude Configurable P9
[FB0 Loss Cfg]
Indicates that the encoder 0 signal amplitude is out of tolerance.
xx087 Ch0 Open Wire Configurable P9
[FB0 Loss Cfg]
Indicates that an open wire condition has been detected for encoder 0.
Both Sine and Cosine signals fell below 0.3 volts.
xx088 Ch0 Quad Loss Configurable P9
[FB0 Loss Cfg]
Indicates that a signal quadrature error has been detected for encoder 0.
Add ferite cores.
xx089 Ch0 Phase Loss Configurable P9
[FB0 Loss Cfg]
Indicates that an A or B signal of an A quad B incremental encoder on
Channel 0 is disconnected.
xx090 Ch0 Unsupp Enc Configurable P9
[FB0 Loss Cfg]
Indicates that the connected encoder on Channel 0 is not supported
xx100 Ch0 FreqExc Alm Alarm 1 P9
[FB0 Loss Cfg]
Alarm reported by Heidenhain Encoder on Channel 0 with EnDat
Interface - Frequency exceeded warning
xx101 Ch0 TempExc Alm Alarm 1 P9
[FB0 Loss Cfg]
Alarm reported by Heidenhain Encoder on Channel 0 with EnDat
Interface - Temperature exceeded warning
xx102 Ch0 LightLim Alm Alarm 1 P9
[FB0 Loss Cfg]
Alarm reported by Heidenhain Encoder on Channel 0 with EnDat
Interface - Limit of light control reserve reached
xx103 Ch0 Battery Alm Alarm 1 P9
[FB0 Loss Cfg]
Alarm reported by Heidenhain Encoder on Channel 0 with EnDat
Interface - Battery warning
xx104 Ch0 RefPoint Alm Alarm 1 P9
[FB0 Loss Cfg]
Alarm reported by Heidenhain Encoder on Channel 0 with EnDat
Interface - Reference point not reached
xx108 Ch0 General Alm Alarm 1 P9
[FB0 Loss Cfg]
Alarm reported by an Encoder on Channel 0 with BiSS Interface - A
warning bit of the BiSS Single Cycle Data is set
xx115 Ch0 Optics Alarm Alarm 1 P9
[FB0 Loss Cfg]
Alarm reported by a linear Stahl encoder on Channel 0 - Displays an
alarm when the Stahl optical system requires cleaning
xx116 Ch0 OutOfRailAlm Alarm 1 P9
[FB0 Loss Cfg]
Alarm reported by a linear Stahl encoder on Channel 0 - Indicates that
the read encoder count is at the maximum value (524287)
xx200 Ch1 LightSrc Err Configurable P39
[FB1 Loss Cfg]
Error reported by Heidenhain Encoder on Channel 1 with EnDat Interface
- Light source failure
xx201 Ch1 SigAmp Err Configurable P39
[FB1 Loss Cfg]
Error reported by Heidenhain Encoder on Channel 1 with EnDat Interface
-Signal amplitude error
xx202 Ch1 PsnVal Err Configurable P39
[FB1 Loss Cfg]
Error reported by Heidenhain Encoder on Channel 1 with EnDat Interface
- Position value error
xx203 Ch1 OverVolt Err Configurable P39
[FB1 Loss Cfg]
Error reported by Heidenhain Encoder on Channel 1 with EnDat Interface
- Overvoltage error
Event
No.
(1)
Fault/Alarm Text Type Fault
Action
Configuration Param Auto
Reset
Description
