Allen-Bradley PowerFlex 750 Series Programming Manual

Rockwell Automation Publication 750-PM001N-EN-P - February 2017 349
Troubleshooting Chapter 6
xx204 Ch1 UndVolt Err Configurable P39
[FB1 Loss Cfg]
Error reported by Heidenhain Encoder on Channel 1 with EnDat Interface
- Undervoltage error
xx205 Ch1 OverCur Err Configurable P39
[FB1 Loss Cfg]
Error reported by Heidenhain Encoder on Channel 1 with EnDat Interface
- Overcurrent error
xx206 Ch1 Battery Err Configurable P39
[FB1 Loss Cfg]
Error reported by Heidenhain Encoder on Channel 1 with EnDat Interface
- Battery empty
xx209 Ch1 AnalSig Err Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Analog signals outside specification
xx210 Ch1 IntOfst Err Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Faulty internal angular offset
xx211 Ch1 DataTabl Err Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Data field partitioning table damaged
xx212 Ch1 AnalLim Err Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Analog limit values not available
xx213 Ch1 Int I2C Err Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Internal I2C bus not operational
xx214 Ch1 IntChksm Err Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Internal checksum error
xx215 Ch1 PrgmResetErr Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Encoder reset occurred as a result of program monitoring
xx216 Ch1 CntOvrflwErr Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Counter overflow
xx217 Ch1 Parity Err Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Parity error
xx218 Ch1 Chksum Err Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Checksum of the data that is transmitted is incorrect
xx219 Ch1 InvCmd Err Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Unknown command code
xx220 Ch1 SendSize Err Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Number of data that is transmitted is incorrect
xx221 Ch1 CmdArgmt Err Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Command argument that is transmitted is not allowed
xx222 Ch1 InvWrtAdrErr Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - The selected data field must not be written to (invalid write
address)
xx223 Ch1 AccCode Err Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Incorrect access code
xx224 Ch1 FieldSizeErr Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Size of data field that is stated cannot be changed
xx225 Ch1 Address Err Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Word address that is stated is outside data field
xx226 Ch1 FieldAcc Err Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Access to non-existent data field
xx228 Ch1 SiTurnPsnErr Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Single turn position unreliable
xx229 Ch1 MulTrnPsnErr Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Multiple turn position unreliable
xx236 Ch1 AnalVal Err Configurable P39
[FB1 Loss Cfg]
Error reported by Stegmann Encoder on Channel 1 with Hiperface
Interface - Analog value error (process data)
Event
No.
(1)
Fault/Alarm Text Type Fault
Action
Configuration Param Auto
Reset
Description
