ALLIANCE 030 Series User Manual

© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Electrical Requirements
70458301ENR6
64
055 Series Gas Models
T30 Series Gas and Steam Models (Total Machine)
Serial Plate Voltage
Terminal Block
Connections Required
Serial Plate Amps Recommended Circuit
Nonreversing Reversing Breaker Rating
Wire Size
AWG (mm
2
)
120V/60Hz/1ph
L1, Neutral, and ground 9.2 N/A 15A – 1 pole 14 (2.5)
208-240V/60Hz/1ph
L1, L2, Neutral, and ground 6.5 N/A 10A – 2 pole 14 (2.5)
100V/60Hz/1ph
L1, Neutral, and ground 9.8 N/A 15A – 1 pole 14 (2.5)
100V/50Hz/1ph
L1, Neutral, and ground 10 N/A 15A – 1 pole 14 (2.5)
200V/50Hz/1ph
L1, Neutral, and ground 6.2 N/A 15A – 1 pole 14 (2.5)
230-240V/50Hz/1ph
L1, Neutral, and ground 5.5 N/A 10A – 1 pole 14 (2.5)
200-208V/60Hz/3ph
L1, L2, L3, and ground 4.0 4.0 10A* – 3 pole 14 (2.5)
240V/60Hz/3ph
L1, L2, L3, and ground 4.0 4.5 10A* – 3 pole 14 (2.5)
380V/50Hz/3ph
L1, L2, L3, and ground 2.0 2.5 10A* – 3 pole 14 (2.5)
400-415V/50Hz/3ph
L1, L2, L3, and ground 2.0 2.5 10A* – 3 pole 14 (2.5)
* 3 Phase machines should not have fuses, breakers only.
N/A = Not Applicable
Table 9
Serial Plate Voltage
Terminal Block
Connections Required
Serial Plate
Amps
Recommended Circuit
Breaker Rating
Wire Size
AWG (mm
2
)
120V/60Hz/1ph
L1, Neutral, and ground 16.0 20A – 1 pole 12 (4)
208-240V/60Hz/1ph
L1, L2, Neutral, and ground 8.0 10A – 2 pole 14 (2.5)
100V/60Hz/1ph
L1, Neutral, and ground 22.0 30A – 1 pole 10 (6)
200-220V/60Hz/1ph
L1, Neutral, and ground 11.6 15A – 1 pole 14 (2.5)
100V/50Hz/1ph
L1, Neutral, and ground 24.2 35A – 1 pole 8 (10)
200/50Hz/1ph
L1, Neutral, and ground 15.0 20A – 1 pole 12 (4)
230-240V/50Hz/1ph
L1, Neutral, and ground 9.0 15A – 1 pole 14 (2.5)
200-208V/60Hz/3ph
L1, L2, L3, and ground 6.4 10A* – 3 pole 14 (2.5)
240V/60Hz/3ph
L1, L2, L3, and ground 6.4 10A* – 3 pole 14 (2.5)
200V/50Hz/3ph
L1, L2, L3, and ground 5.8 10A* – 3 pole 14 (2.5)
230-240V/50Hz/3ph
L1, L2, L3, and ground 7.0 10A* – 3 pole 14 (2.5)
380V/50 or 60Hz/3ph
L1, L2, L3, and ground 3.0 10A* – 3 pole 14 (2.5)
400-415V/50Hz/3ph
L1, L2, L3, and ground 3.2 10A* – 3 pole 14 (2.5)
440V/60Hz/3ph
L1, L2, L3, and ground 3.3 10A* – 3 pole 14 (2.5)
460-480V/60Hz/3ph
L1, L2, L3, and ground 3.3 10A* – 3 pole 14 (2.5)
* 3 Phase machines should not have fuses, breakers only.
Table 10
