Electrical Requirements
67
70458301ENR6
24 kW 035 Series Electric Models
Table 16
27 kW 055 Series Electric Models
Table 17
Serial Plate Voltage
Terminal Block
Connections Required
Serial Plate Amps Recommended Circuit
Nonreversing Reversing Breaker Rating
Wire Size
AWG (mm
2
)
208V/60Hz/1ph
L1, L2, Neutral, and ground 122 N/A 175A – 2 pole 2/0 (70)
240V/60Hz/1ph
L1, L2, Neutral, and ground 107 N/A 150A – 2 pole 1/0 (50)
200V/60Hz/1ph
L1, Neutral, and ground 122 N/A 175A – 1 pole 2/0 (70)
200V/50Hz/1ph
L1, Neutral, and ground 119 N/A 150A – 1 pole 1/0 (50)
230-240V/50Hz/1ph
L1, Neutral, and ground 108 N/A 150A – 1 pole 1/0 (50)
200-208V/60Hz/3ph
L1, L2, L3, and ground 71 71 90A* – 3 pole 3 (26.7)
200V/50Hz/3ph
L1, L2, L3, and ground 65 65 90A* – 3 pole 3 (26.7)
230-240V/50Hz/3ph
L1, L2, L3, and ground 62 N/A 80A* – 3 pole 4 (25)
240V/60Hz/3ph
L1, L2, L3, and ground 62 62 80A* – 3 pole 4 (25)
380V/50 or 60Hz/3ph
L1, L2, L3, and ground 38 38 50A* – 3 pole 6 (16)
400-415V/50Hz/3ph
L1, L2, L3, and ground 35 35 45A* – 3 pole 8 (10)
440V/60Hz/3ph
L1, L2, L3, and ground 33 N/A 45A* – 3 pole 8 (10)
460-480V/60Hz/3ph
L1, L2, L3, and ground 31 31 40A* – 3 pole 8 (10)
* 3 Phase machines should not have fuses, breakers only.
N/A = Not Applicable
Serial Plate Voltage
Terminal Block
Connections Required
Serial Plate Amps Recommended Circuit
Nonreversing Reversing Breaker Rating
Wire Size
AWG (mm
2
)
208V/60Hz/1ph
L1, L2, Neutral, and ground 129 N/A 175A – 2 pole 2/0 (70)
240V/60Hz/1ph
L1, L2, Neutral, and ground 115 N/A 150A – 2 pole 1/0 (50)
200V/60Hz/1ph
L1, Neutral, and ground 122 N/A 175A – 1 pole 2/0 (70)
200V/50Hz/1ph
L1, Neutral, and ground 131 N/A 175A – 1 pole 2/0 (70)
230-240V/50Hz/1ph
L1, Neutral, and ground 119 N/A 150A – 1 pole 1/0 (50)
200-208V/60Hz/3ph
L1, L2, L3, and ground 79 79 100A* – 3 pole 3 (26.7)
240V/60Hz/3ph
L1, L2, L3, and ground 65 65 80A* – 3 pole 4 (25)
380V/50Hz/3ph
L1, L2, L3, and ground 43 43 60A* – 3 pole 8 (10)
400-415V/50Hz/3ph
L1, L2, L3, and ground 38 38 50A* – 3 pole 8 (10)
* 3 Phase machines should not have fuses, breakers only.
N/A = Not Applicable
