Electrical Requirements
70458301ENR6
66
21 kW 030 Series Electric Models
Table 14
21 kW T30 Series Electric Models
Table 15
Serial Plate Voltage
Terminal Block
Connections Required
Serial Plate Amps Recommended Circuit
Non-
reversing
Reversing Breaker Rating
Wire Size
AWG (mm
2
)
208V/60Hz/1ph
L1, L2, Neutral, and ground 108 N/A 150A – 2 pole 1/0 (50)
240V/60Hz/1ph
L1, L2, Neutral, and ground 94 N/A 125A – 2 pole 1 (35)
200V/60Hz/1ph
L1, Neutral, and ground 108 N/A 150A – 1 pole 1/0 (50)
200V/50Hz/1ph
L1, Neutral, and ground 105 N/A 150A – 1 pole 1/0 (50)
230-240V/50Hz/1ph
L1, Neutral, and ground 95 N/A 125A – 2 pole 1 (35)
200-208V/60Hz/3ph**
L1, L2, L3, and ground 62 62 80A* – 3 pole 4 (25)
200V/50Hz/3ph**
L1, L2, L3, and ground 60 60 80A* – 3 pole 4 (25)
230-240V/50Hz/3ph**
L1, L2, L3, and ground 55 N/A 70A* – 3 pole 4 (25)
240V/60Hz/3ph**
L1, L2, L3, and ground 54 54 70A* – 3 pole 4 (25)
380V/50 or 60Hz/3ph**
L1, L2, L3, and ground 33 33 45A* – 3 pole 8 (10)
400-415V/50Hz/3ph**
L1, L2, L3, and ground 31 31 40A* – 3 pole 8 (10)
440V/60Hz/3ph
L1, L2, L3, and ground 29 N/A 40A* – 3 pole 8 (10)
460-480V/60Hz/3ph**
L1, L2, L3, and ground 27 27 35A* – 3 pole 8 (10)
* 3 Phase machines should not have fuses, breakers only.
** These serial plate voltages are only options available on the 30 series electric models.
N/A = Not Applicable
Serial Plate Voltage
Terminal Block
Connections Required
Serial Plate
Amps
Recommended Circuit
Breaker Rating
Wire Size
AWG (mm
2
)
200-208V/60Hz/3ph*
L1, L2, L3, and ground 62** 80A – 3 pole 4 (25)
200V/50Hz/3ph*
L1, L2, L3, and ground 60** 80A – 3 pole 4 (25)
230-240V/50Hz/3ph*
L1, L2, L3, and ground 55** 70A – 3 pole 4 (25)
240V/60Hz/3ph*
L1, L2, L3, and ground 54** 70A – 3 pole 4 (25)
380V/50 or 60Hz/3ph*
L1, L2, L3, and ground 33** 45A – 3 pole 8 (10)
400-415V/50Hz/3ph*
L1, L2, L3, and ground 31** 40A – 3 pole 8 (10)
440V/60Hz/3ph
L1, L2, L3, and ground 29** 40A – 3 pole 8 (10)
460-480V/60Hz/3ph
L1, L2, L3, and ground 27** 35A – 3 pole 8 (10)
* These serial plate voltages are only options available on the T30 electric models. Current (Amp) is for one pocket only.
** Per heater on T30 electric models, each has two heaters.
