Allied Systems Freeman 370 - Battery Strap & Cable Mounting; Flywheel Belt Mounting

Engine Installation, 37X
Page 2 of 4
Engine Installation, 37X
Page 2 of 4
FLYWHEEL BELT MOUNTING
BELT SHIELD NOT SHOWN
370/375 BALER SHOWN
BATTERY STRAP & CABLE MOUNTING
370/375 BALER SHOWN
DETAIL A
1
8
RED 12 GA WIRE
FROM CONTROL BOX
HARNESS
3
NEG
POS
REFERENCE EXISTING BATTERY
CABLE ON ENGINE ASSEMBLY
2-2
2-1
A
REFERENCE
#BAT0277000
12V BATTERY
2-4
2-3
REFERENCE
EXISTING BATTERY
CABLE ON ENGINE
ASSEMBLY
RECOMENDED BELT TENSION
BELT DEFLECTION FORCE
F000007000 0.75" 16 LB
256812 0.63" 16 LB
2-1
17
