Allied Systems Freeman 370 - Harness and Control Box Installation

Engine Assembly
Page 4 of 4
Engine Assembly
Page 4 of 4
DETAIL C
CONTROL BOX MOUNTING
CLIP FOR ENGINE HARNESS
DETAIL J
REF. FASTENERS
1
15
40 16X
37
33
20
26
4X
2X
WASHER LOCATED
BETWEEN BOX & ENGINE.
CAPSCREW AND WASHER
LOCATED INSIDE BOX.
PRE-PAINT
PLUG HOLES
WITH SILICONE.
CONTROL BOX ASSEMBLY
C
J
PRE-PAINT
PLUG HOLES
WITH SILICONE.
PRE-PAINT
INSTALL SOFT PLUG
(PROVIDE WITH ENGINE).
PRE-PAINT
TAPE ITEM 7
OPENING SHUT.
47
4849
50
REMOVE EXISTING HARDWARE.
3-1
3-1
NOTES:
INSTALL ITEMS 47, 48, AND 49 AT THIS LEVEL,
THEY ARE CALLED OUT ON THE SNORKEL INSTALL.
INSTALL ENGIN HARNESS IN CLIP AS SHOWN.
3-2
3-2
HARNESS INSTALL
CONTROLL BOX
90° ELBOW
FUEL GAUGE
TEMP SENSOR
CONNECTORS
CLIP
LIGHTS
BATTERY
OLENOID
ALTERNATOR
ENGINE HARNESS
23
89-096Rev: 11-2016
