Chamber Installation Gearbox 3 Tie
14x22,15x22,16x22
Page 3 of 11
Chamber Installation Gearbox 3 Tie
14x22,15x22,16x22
Page 3 of 9
Item Part Number Description
905058 16" CHM, Conv. Knot
906975 15" CHM, Conv. Knot
906309 14" CHM, Conv. Knot
907036 16" CHM, Tailless Knot
907037 15" CHM, Tailless Knot
907038 14" CHM, Tailless Knot
Quantity
31 Y09G-0516 Capscrew 37 32 32 40 32 32
32 Y09G-0520 Capscrew 16 4 4 16 4 4
33 Y09G-0524 Capscrew 9 9 9 10 10 10
34 Y09G-0528 Capscrew 7 3 3 7 3 3
35 Y09G-0532 Capscrew 1 18 0 0 18 0
36 Y09G-0536 Capscrew 2 14 2 0 12 0
37 Y09G-0544 Capscrew 0 4 0 1 5 1
38 Y09G-0548 Capscrew 0 0 12 0 0 12
39 Y09G-0556 Capscrew 0 0 12 0 0 12
40 Y09G-0564 Capscrew 0 0 4 0 0 4
41 223428 Washer, Flat 17 15 15 15 15 15
42 R13812513 Washer, Lock 61 74 74 63 73 73
43 R13811512 Nut, Hex 65 75 75 63 73 73
44 CRB3750150 Bolt, Carriage 3 0 0 3 0 0
45 CRB3750250 Bolt, Carriage 0 3 0 0 3 0
46 CRB3753500 Bolt, Carriage 0 0 3 0 0 3
47 Y17C-0624 Capscrew 6 0 0 6 0 0
48 180959W Capscrew 0 6 0 0 8 0
49 R13811045 Capscrew 0 0 6 0 0 6
51 F000007744 14” Stationary Knife 0 0 1 0 0 1
52 KNF0018468 15” Stationary Knife 0 1 0 0 1 0
53 F000001609 Stationnary Knife, Sq Holes 1 0 0 1 0 0
54 PWB5002000 Bolt, Plow 4 4 3 4 4 3
55 223587 Nut, Esna 4 4 3 4 4 3
56 903368 Adapter Wldmt: Chamber 0 0 1 0 0 1
57 DPT0034314 Adaptor Chamber, 15” 0 1 0 0 1 0
58 R13801840 Capscrew 0 4 4 0 4 4
98
89-096 Rev: 11-2016
