Allied Systems Freeman 370 User Manual

Chamber Installation Gearbox 3 Tie
14x22,15x22,16x22
Page 4 of 11
Chamber Installation Gearbox 3 Tie
14x22,15x22,16x22
Page 4 of 9
Item Part Number Description
905058 16" CHM, Conv. Knot 906975 15" CHM, Conv. Knot 906309 14" CHM, Conv. Knot 907036 16" CHM, Tailless Knot 907037 15" CHM, Tailless Knot 907038 14" CHM, Tailless Knot
Quantity
59 R13812516 Washer, Lock 0 4 4 0 4 4
60 SQS5001750 Sq Head Set Screw 2 2 1 2 2 1
61 234218 Nut, Jam 2 0 1 2 0 1
62 903119 Needle Track Block, 14" Chamber 0 0 3 0 0 3
63 902703 Needle Track Block, Sq Edge 3 3 0 3 3 0
64 Y17C-1028 Capscrew 0 0 1 0 0 1
65 222462 Nut, Jam 1 0 1 0 0 1
71 MNT037222A Trip Arm Spring Mount 1 1 1 0 0 0
72 SPC0033118 Bullgear Bolt Pin Spacer 0 0 0 1 1 1
73 232939 Nut, Esna 2 2 2 0 0 0
74 R13811017 Capscrew 1 1 1 0 0 0
81 903370 Rear Conv Spacer Rail, RH, 16" to 14" 0 0 1 0 0 1
82 903371 Rear Conv Spacer Rail, LH, 16" to 14" 0 0 1 0 0 1
83 SPC035753B Rear Conversion Spacer, Rail 0 2 2 0 2 2
84 SPC0018514 Conversion Spacer, 1 3/8" x 2" 0 4 8 0 4 8
85 SPC0018515 Conversion Spacer, 2" x 4" 0 4 8 0 4 8
86 SPC0018516 Rear Conversion Spacer, 2" x 4" 0 3 6 0 3 6
87 SPC0018517 Front Conversion Spacer, 2" x 16 1/8" 0 1 2 0 1 2
88 SPC0018519 Plunger Rail Conversion Spacer 0 1 2 0 1 2
89 906308 Plunger Rail Spacer 0 1 2 0 1 2
99
89-096Rev: 11-2016
