AT-MMC6000 Series Installation Guide
25
Table 3. VDSL2 DIP Switch Settings - Additional Information
DIP Switch
Bandwidth
(MHz)
Max
Loop
Length*
Max Data Rate
(Mbps)
Downstream/
Upstream**
Symmetric/
Asymmetric
G.inp
Data
Interleaving
234
Up Up Up 17 <2.5 km
(8k ft)
90/40 Asymmetric No Yes
Up Up Down 30 <1 km
(35k ft)
150/150 Symmetric No Yes
Up Down Up 30 <1 km
(35k ft)
180/100 Asymmetric No No
Up Down Down 30 <750 m
(2.5k ft)
100/100 Symmetric Yes Yes
Down Up Up 8 <4 km
(13k ft)
65/15 Asymmetric No Yes
Down Up Down 17 <2.5 km
(8k ft)
75/75 Symmetric No Yes
Down Down Up 17 <2 km
(6k ft)
90/40 Asymmetric Yes Yes
Down Down Down 30 <1 km
(35k ft)
180/100 Asymmetric No Yes
*Laboratory measurements provided for reference only. Actual data rate depends on network topology and is
reduced by factors, such as interference and bridge taps.
**Maximum data rates are attainable at very short loops. As a function of DSL technology, the maximum data rate
rolls off as the length of wire increases.
Note: All settings have a 6dB noise margin.
