Chapter 5 Detailed Function Introductions
110
 Open valid: Signal is disabled if the control terminal and COM terminal are short-circuited. (Normally open
and normally close are not limited)
3004GB and below models:
P3.01 P3.01 Multi-function input selection Terminal
X1
Setting range: 0~79 [1]
P3.02 P3.01 Multi-function input selection Terminal
X2
Setting range: 0~79 [2]
P3.03 P3.01 Multi-function input selection Terminal
X3
Setting range: 0~80 [37]
P3.04 P3.01 Multi-function input selection Terminal
X4
Setting range: 0~81 [0]
P3.05 P3.01 Multi-function input selection Terminal
X5
Setting range: 0~82 [0]
P3.06 Reserved -
P3.07 Reserved -
P3.08 Reserved -
P3.09 Reserved -
P3.10 Reserved -
P3.11 Reserved -
P3.12 Reserved -
35R5GB and above models:
P3.01 Multi-function input selection Terminal X1
Setting range: 0~79 [1]
P3.02 Multi-function input selection Terminal X2
Setting range: 0~79 [2]
P3.03 Multi-function input selection Terminal X3
Setting range: 0~79 [37]
P3.04 Multi-function input selection Terminal X4
Setting range: 0~80 [0]
P3.05 Multi-function input selection Terminal X5
Setting range: 0~81 [0]
P3.06 Multi-function input selection Terminal X6
Setting range: 0~82 [0]
P3.07 Multi-function input selection Terminal X7
Setting range: 0~79 [0]
P3.08 Multi-function input selection Terminal X8
Setting range: 0~79 [0]
P3.09 Multi-function input selection Terminal X9
Setting range: 0~79 [0]
P3.10 Multi-function input selection Terminal X10
Setting range: 0~79 [0]
P3.11 Multi-function input selection Terminal X11
Setting range: 0~79 [0]
P3.12 Reserved
-
Notes:
 Control terminals X1 ~ X10 are multi-function terminals, their specific functions can be defined by setting
the value of P3.01 ~ P3.10. Allow duplicate definitions, among repeatedly defined terminals, when one
terminal is active, this function is enabled. Set points and functions are as shown in Table 5-3-1.
