Table 5-3-1 Multi-function Input Menu
Setting Function Setting Function
0 NULL: No defined 1 FWD: Running Forward
2 REV: Running Reverse 3 RUN
4 F/R: Running direction 5 HLD: self-hold selection
6 RST: reset 7 FC: Setting frequency selection
8 FJOG: JOG FWD 9 RJOG: JOG REV
10 UP 11 DOWN
12 UP/DOWN Reset 13 FRE: Coast-to-stop
14
Forced stopping (Deceleration time
according to abnormal stopping)
15 DC braking
16 Acc/Dec prohibit 17 Inverter running prohibit
18 S1 Multi-step Speed 1 19 S2 Multi-step Speed 2
20 S3 Multi-step Speed 3 21 S4 Multi-step Speed 4
22 S5 Multi-step Speed 5 23 S6 Multi-step Speed 6
24 S7 Multi-step Speed 7 25
Command channel switch to Terminal
control 2
26 SS1 Multi-step Speed 27 SS2 Multi-step Speed
28 SS3 Multi-step Speed 29 SS4 Multi-step Speed
30 T1 Acc/Dec time 1 31 T2 Acc/Dec time 2
32 T3 Acc/Dec time 3 33 T4 Acc/Dec time 4
34 TT1 Acc/Dec time 35 TT2 Acc/Dec time
36 Forced outage normally close 37 EH0: External fault signal normally open
38 EH1: External fault signal normally close 39
EI0: External interrupt signal normally
open
40
EI1: External interrupt signal normally
close
41 Stopping plus DC brake
42 Start PLC operation 43 Pause the PLC operating
44 Reset PLC stop status 45 Start wobble frequency operation
46
Reset the wobble frequency operating
status
47 Start PID operation
48 Speed/torque mode switching 49 Timing drive input
50 Counter trig signal input 51 Counter clear
54 Reserved 55 Reserved
56 Reserved 57 Reserved
58 Reserved 59 Reserved
60 Reserved 61 Reserved
