Alpha PowerBay BDFB - Product Specifications; BDFB Main Unit Specifications; Breaker Panel Specifications

20
C048-740-30 R02, Rev. C (01/2020)
5.0 5.0 Product SpecicationsProduct Specications
5.1 5.1 PowerBay+ Full-Size BDFB SpecicationsPowerBay+ Full-Size BDFB Specications
Table 7. Mechanical
Width 26 in.
Height 84 in.
Depth 28 in.
Weight 775 lbs.
Table 8. Electrical
Voltage -48VDC
Load Current Per Bus 960A Max. Continuous
Number of Busses 2, 4, 6, or 8
Alarm Contacts Form-C, 60VDC @ 0.5A Max.
Circuits Up to 176
Input Current 7680A Max.
Maximum Input Interruption
Device
1200A
Interrupt Rating 10000A
Table 9. Environmental
Temperature 0 to 40ºC Operating
Humidity 0 to 95% RH Non-Condensing
Elevation -500 to 3000m
Table 10. Approvals
UL File Number E473904
UL Standard ANSI/UL 60950-1
5.2 5.2 AM Breaker Panel SpecicationsAM Breaker Panel Specications
Table 11. Mechanical (All Models)
Width 9 in.
Height 20 in.
Depth 10.5 in.
