Alpha PowerBay BDFB - Appendix D: Supported Lugs; Lugs for Input Connections; Lugs for Output Connections

48
C048-740-30 R02, Rev. C (01/2020)
Appendix D: Appendix D: Supported Lugs For TerminationSupported Lugs For Termination
Table 22. Supported Lugs for Input Connections
WIRE GAUGE
SUPPORTED
PART
NUMBER
DESCRIPTION MANUFACTURER MANUFACTURER
PART NUMBER
CRIMP DIE
REQUIRED
4/O AWG C538-102-10 Lug; Long Barrel; 3/8"
holes; 1" CTC
Burndy YAZV282TC38FX Burndy U28RT,
W28V T, W28CRT,
X28RT
4/O AWG C538-133-10 Lug; Standard Barrel;
3/8" holes; 1" CTC
Burndy YAV28L2TC38FX Burndy U28RT,
W28V T, W28RT,
X28RT
4/O AWG C538-220-10 Lug; Standard Barrel;
Narrow Tongue; 3/8"
holes; 1" CTC
Burndy YAV28L2NT38FX Burndy U28RT,
W28V T, W28RT,
X28RT
4/O AWG C538-221-10 Lug; Long Barrel;
Narrow Tongue; 3/8"
holes; 1" CTC
Burndy YAZV282NT38FX Burndy U28RT,
W28V T, W28RT,
X28RT
4/O AWG C538-245-10 Lug; Short Barrel;
Narrow Tongue; 3/8"
holes; 1" CTC
Burndy YAV29L2NT38FX Burndy U29RT,
W29VT, W29 RT,
X29RT
350 MCM C538-070-10 Lug; Long Barrel; 3/8"
holes; 1" CTC
Burndy YAZ342NT38FX Burndy U32RT,
W32VT, W32RT
350 MCM C538-118-10 Lug; Standard Barrel;
3/8" holes; 1" CTC
Burndy YA34L2TC38FX Burndy U32RT,
W32VT, W32RT
500 MCM C538-072-10 Lug; Long Barrel; 3/8"
holes; 1" CTC
Burndy YAZ382NT38FX Burndy U38XRT
500 MCM C538-131-10 Lug; Standard Barrel;
3/8" holes; 1" CTC
Burndy YA38L2NT38FX Burndy U38XRT
750 MCM C538-073-10 Lug; Long Barrel; 3/8"
holes; 1" CTC
Burndy YAZ442NT38FX Burndy U44XRT
750 MCM C538-138-10 Lug; Standard Barrel;
3/8" holes; 1" CTC
Burndy YA44L2NT38FX Burndy U44XRT
Table 23. Supported Lugs for Output Connections (Internal Returns)
WIRE GAUGE
SUPPORTED
PART
NUMBER
DESCRIPTION MANUFACTURER MANUFACTURER
PART NUMBER
CRIMP DIE
REQUIRED
#6 AWG C538- 094-10 Lug; Long Barrel; 1/4"
holes; 5/8" CTC
Burndy YAZV282TC38FX Burndy U5CRT,
W5CVT, W5CR,
X5CRT
#4 AWG C538-085-10 Lug; Long Barrel; 1/4"
holes; 5/8" CTC
Burndy YAZV4C2TC14FX Burndy U4CRT,
W2CV T, W2CRT,
X2CRT
#2 AWG C538-173-10 Lug; Short Barrel; 1/4"
holes; 5/8" CTC
Burndy YAV2CL2NT14FX Burndy U2CRT,
W4CV T, W4CRT,
X4CRT
Table 24. Supported Lugs for Output Connections (AM Breaker Panel)
WIRE GAUGE
SUPPORTED
PART
NUMBER
DESCRIPTION MANUFACTURER MANUFACTURE
PART NUMBER
CRIMP DIE
REQUIRED
#6 AWG C538- 094-10 Lug; Long Barrel; 1/4"
holes; 5/8" CTC
Burndy YAZV282TC38FX Burndy U5CRT,
W5CVT, W5CR,
X5CRT
#4 AWG C538-085-10 Lug; Long Barrel; 1/4"
holes; 5/8" CTC
Burndy YAZV4C2TC14FX Burndy U4CRT,
W2CV T, W2CRT,
X2CRT
#2 AWG C538-173-10 Lug; Short Barrel; 1/4"
holes; 5/8" CTC
Burndy YAV2CL2NT14FX Burndy U2CRT,
W4CV T, W4CRT,
X4CRT
