Alpha PowerBay BDFB - Supported Output Lugs for GJ Panels; GJ Breaker Panel Lug Support

49
C048-740-30 R02, Rev. C (01/2020)
Table 25. Supported Lugs for Output Connections (GJ breaker panel)
WIRE
GAUGE
SUPPORTED
PART
NUMBER
DESCRIPTION MANUFACTURER MANUFACTURE
PART NUMBER
CRIMP DIE
REQUIRED
4/O AWG C538-102-10 Lug; Long Barrel; 3/8"
holes; 1" CTC
Burndy YAZV282TC38FX Burndy U28RT,
W28V T, W28RT,
X28RT
4/O AWG C538-133-10 Lug; Standard Barrel;
3/8" holes; 1" CTC
Burndy YAV28L2TC38FX Burndy U28RT,
W28V T, W28RT,
X28RT
4/O AWG C538-220-10 Lug; Standard Barrel;
Narrow Tongue; 3/8"
holes; 1" CTC
Burndy YAV28L2NT38FX Burndy U28RT,
W28V T, W28RT,
X28RT
4/O AWG C538-221-10 Lug; Long Barrel;
Narrow Tongue; 3/8"
holes; 1" CTC
Burndy YAZV282NT38FX Burndy U25RT,
W25V T, W25RT,
X25RT
4/0 AWG C538-245-10 Lug; Short Barrel;
Narrow Tongue; 3/8"
holes; 1" CTC
Burndy YAV29L2NT38FX Burndy U29RT,
W29VT, W29 RT,
X29RT
350 MCM C538-070-10 Lug; Long Barrel; 3/8"
holes; 1" CTC
Burndy YAZ342NT38FX Burndy U32RT,
W32VT, W32RT
350 MCM C538-118-10 Lug; Standard Barrel;
3/8" holes; 1" CTC
Burndy YA34L2TC38FX Burndy U32RT,
W32VT, W32RT
