101
DJM-V10
5
6 7 8
5
6 7 8
A
B
C
D
E
F
Put Barrier to the hook.
Bend Barrier (2nd) Put Barrier to the hook.
Pass FFC in slit of Barrier.
Put Barrier to the hook.
With hook as the fulcrum, turn it to
the direction of the arrow.
Bend FFC in conformity to the line
on the silk.
Bend Barrier (1st)
BFXB Assy
7 Remove the one screw.
(BPZ30P100FTB)
8 Remove the 4 screws and then remove the
BFXB Assy.
(BBZ30P060FTC)
g Barrier and FFC styling
OK NG
• Bottom view
7
8
8
8
8
1
2
3
Screw tightening order
PlatePlate
DEC3860DEC3860
DEC3861
DEC3861
DEC3861
DEC3861
DEC3861
DEC3861
DEC3929
DEC3929
DEC3929
DEC3929
