AlphaTheta DJM-V10 - Page 67

67
DJM-V10
5
6 7 8
5
6 7 8
A
B
C
D
E
F
Operating button Lighting level indicator
CUE A button
CH1
Channel level indicator
CH1
CUE A button
CH2
Channel level indicator
CH2
CUE A button
CH3
Channel level indicator
CH3
CUE A button
CH4
Channel level indicator
CH4
CUE A button
CH5
Channel level indicator
CH5
CUE A button
CH6
CUE A button
MASTER
Channel level indicator
CH6
Master level indicator
L CH / CLIP indicator
CUE B button
MASTER
Master level indicator
R CH
Mode 12: Level meter LED checking mode
It is a mode checking lighting of the level indicator LED.
[Functional overview]
LEVEL METER TEST
[Mode Title Display]
[CUE A button CH1 to CH6] : level indicator LED light on
[CUE A button MASTER], [CUE B button MASTER] : level indicator LED light on
[TAP button] (Lighting) : Mode change (to next mode)
[BEAT FX ON/OFF button] (Lighting) : Mode change (to previous mode)
[Element]
When each CUE button is pressed, the corresponding level indicator LED light on one by one from the bottom.
(Including CLIP indicator LED)
The default value is all light off.
If each CUE button is pressed after it is pressed 15 times (the top of the level indicator LED is light on), all light on.
When it is pressed one more time, all light off again.
Only Master level indicator L CH: When Master level indicator L CH is pressed again after it is pressed 16 times
(CLI Pindicator LED light on), all light on. When it is pressed again, all light off again.
[Details]
[Correspondence table]
None
[Notes]
Mode 13: VOL A/D checking mode
It is a mode checking on fluctuation range of the AD value of the rotary volume with Touch display.
This mode is used for Design and for Development. Not used in Service.
[Functional overview]
Mode 14: Fader A/D checking mode
It is a mode checking on fluctuation range of the AD value of the fader with Touch display.
[Functional overview]
