[1-3] Control panel and Panel
1 Remove the 4 screws.
(BBZ30P060FTC)
2 Remove the 4 screws.
(BBZ30P060FTB)
3 Remove the 25 screws and then remove the
Control panel and Panels.
(DBA1451)
1
1
2 2 2 2
1 1
Panel Control panel
• Front view
• Rear view
BBZ30P060FTC
Caution :
Be sure to use the following screw at the
reassembling!
BBZ30P060FTB
Caution :
Be sure to use the following screw at the
reassembling!
DBA1451
Caution :
Be sure to use the following screw at the
reassembling!
1 2
3
4
Screw tightening order
1 2 3 4
