×12×12
[1-4] Control panel Section
1 Remove the 12 Sheets.
Control panel (Bottom view)
1
7
4
5 2
6
9
10
17
20
11
12
13
14 15 16
18
19
8
3
Screw tightening order
12
5 4 3
Note:
When you remove Control Panel and Panel, assemble it from Control Panel surely.
g Notes on assembling / disassembling
Since the Lens (DEH1110) is fixed with DS tape, it cannot be reused.
When attaching it, make sure that the DS tape does not
protrude from the hole of the Control panel.
Be careful not to lost Lens.
Be careful not to
lost Lens.
Be careful not to lost Holder.
1
To Next Page
