AlphaTheta DJM-V10 - Page 84

84
DJM-V10
1
2 3 4
A
B
C
D
E
F
1
2 3 4
1
2
×15×15
2
×3×3
-1
-1
2
-2-2
[2-5] Shield plate
1 Remove the 15 screws.
(BBZ30P060FTC)
[2-6] AIN Assy
1 Remove the 2 screws.
(BBZ30P060FTC)
2 Disconnect the 3 connectors.
(CN4003, 4004, 4005)
2 Lift the right side of Shield plate and then
remove it in the direction of the arrow.
AIN AssyAIN Assy
1
1
Shield plate
Shield plate
Cord clamper
CN4003CN4003
CN4004
CN4004
CN4005
CN4005
1
1
2
5
3
2
6
7
8
10
1112
13 14 15
9
4
Screw tightening order
Screw tightening order
Notes on assembling
Pass the cable from the hole.
