8 Stand the AIN Assy in the fig.
9 Reconnect the Control panel Section etc.
7 Pull out the AIN Assy to front direction
and then remove it.
Control panel Section
AIN Assy
AIN Assy
MAIN Assy
SW POWER
SUPPLY
PSWB
Assy
REGB Assy
AOUT Assy
SNRT1 Assy
SNRT2 Assy
HPPW Assy
HPJM Assy
HPJK Assy
SNRT3
Assy
