AlphaTheta DJM-V10 - Page 91

91
DJM-V10
5
6 7 8
5
6 7 8
A
B
C
D
E
F
[3-6] HPPW Assy
1 Disconnect the one FFC and one connector.
(CN6351, 6352)
2 Remove the 6 screws and then remove the
HPPW Assy.
(ABZ30P060FTC)
[3-7] MAIN and AOUT Assy
1 Remove the one screw and then remove the
Stay.
(BBZ30P060FTC)
2 Disconnect the one bridge connector.
(CN5402)
3 Disconnect the one FFC and one connector.
(CN4, 6)
4 Remove the 15 screws.
(BBZ30P060FTC)
HPPW Assy
HPPW Assy
REGB Assy
MAIN Assy
CN12CN12
CN6352
CN6352
CN6351
CN6351
CN6351
CN6351
PressPress
Press
Press
CN13CN13
1
1
4
5
6 7
10
11
12
13
14
15
9
8
2
3
4 6
5
32
Screw tightening order
g Jumper wires styling
1
1
2
×6×6
MAIN Assy StayAOUT Assy
CN5CN5
CN4
CN4
CN5402
CN5402
CN5403
CN5403
CN5401
CN5401
CN6
CN6
2
1
3
3
4
×15×15
